Case Write-Up: Acute Appendicitis

PATIENT DETAILS

Name: Mr. K.O. Age: 22 years Sex: Male Occupation: University student Date of Admission: July 11, 2026

1. HISTORY

Presenting Complaint

Right iliac fossa (RIF) pain of 18 hours duration.

History of Presenting Illness

Mr. K.O. is a 22-year-old male student who presented to the Emergency Department with an 18-hour history of abdominal pain. He reports that the pain began the previous afternoon as a poorly localised, colicky discomfort in the periumbilical region. It was initially mild to moderate and intermittent in character. He had not eaten since the pain began (anorexia), and he vomited once approximately 2 hours after the pain started -- he correctly noted that the vomiting followed, rather than preceded, the onset of pain. Over the next 8-10 hours, the pain gradually shifted from the central abdomen and became localised to the right iliac fossa, where it changed in character from colicky to constant and more intense. He found that coughing and walking worsened the pain, and he was most comfortable lying still with his right hip slightly flexed.

He denies any change in bowel habit. He has not had diarrhoea. He reports no haematuria, urinary frequency, or dysuria. He has no current upper respiratory symptoms. He has no history of similar episodes, no recent foreign travel, and no significant sick contacts.

Systemic Review

Gastrointestinal: Anorexia since onset. One episode of vomiting. No diarrhoea, no rectal bleeding, no change in stool colour.
Genitourinary: No dysuria, no haematuria, no urethral discharge.
Respiratory: No cough, no shortness of breath.
All other systems: Unremarkable.

Past Medical/Surgical History

No previous abdominal surgery.
No known medical conditions.
No known drug allergies (NKDA).

Drug History

Nil regular medications.
Took paracetamol 1 g orally ~6 hours before presentation with minimal relief.

Family History

No first-degree relatives with inflammatory bowel disease or colorectal cancer.
Father had a hernia repair in his 40s.

Social History

Non-smoker.
Occasional alcohol (weekends).
No illicit drug use.
Lives in university accommodation with flatmates.

2. PHYSICAL EXAMINATION

General Inspection

The patient is alert and oriented. He appears flushed and uncomfortable. He is lying still on the trolley, reluctant to move, with his right hip slightly flexed. He is not jaundiced, not pale, not cyanosed. There is no peripheral lymphadenopathy.

Vital Signs

Parameter	Value
Temperature	37.9 °C (low-grade pyrexia)
Heart Rate	98 bpm (regular)
Blood Pressure	118/76 mmHg
Respiratory Rate	18 breaths/min
O2 Saturation	99% on room air
GCS	15/15

Abdominal Examination

Inspection: Abdomen is flat and moves with respiration. No distension. No visible peristalsis. No obvious scars or hernias. He guards slightly on deep inspiration.

Palpation:

Superficial palpation: Voluntary guarding in the RIF.
Deep palpation: Maximum tenderness at McBurney's point (one-third of the way from the anterior superior iliac spine to the umbilicus). The patient is asked to point to where it hurts most with one finger -- he points directly to McBurney's point (positive pointing sign).
Rovsing's sign: Positive -- palpation of the left iliac fossa produces pain in the right iliac fossa, indicating parietal peritoneal irritation on the right.
Psoas sign: Positive -- passive extension of the right hip with the patient lying on his left side produces RIF pain, suggesting the inflamed appendix lies in a retrocaecal position or is in contact with the psoas muscle.
Obturator sign: Equivocal -- internal rotation of the flexed right hip produces mild RIF discomfort.
Rebound tenderness: Present at McBurney's point -- gentle pressure followed by sudden release produces pain greater than the pressure itself, indicating peritoneal irritation.
No palpable mass.
Liver and spleen not palpable. No organomegaly.

Percussion: Percussion tenderness over the right iliac fossa. No shifting dullness.

Auscultation: Bowel sounds present but diminished. No bruits.

Rectal Examination: Performed. Tenderness on the right side of the rectovesical pouch. No mass palpable. Glove: no blood.

Genitalia: Both testes palpated in the scrotal sac -- no tenderness, no swelling (testicular torsion excluded).

Other Systems

Cardiovascular: Heart sounds I and II heard, no added sounds. No peripheral oedema.
Respiratory: Chest clear bilaterally. No crackles or wheeze. Diaphragm moves normally.
Neurological: No focal deficit.

3. INVESTIGATIONS

Alvarado Score (MANTRELS)

Feature	Score
Migration of pain to RIF	1
Anorexia	1
Nausea/vomiting	1
RIF tenderness	2
Rebound tenderness	1
Elevated temperature (>37.3°C)	1
Leukocytosis (WBC >10,000)	2
Shift of WBC to left	1
Total	9/10

Score of 7-10 = High probability of appendicitis. Score of 9 strongly supports the diagnosis and warrants surgical consultation.

Blood Tests

Investigation	Result	Reference Range
WBC (White Blood Cell Count)	14.2 × 10⁹/L	4.0-11.0 × 10⁹/L
Neutrophils	11.8 × 10⁹/L (83%)	2.0-7.5 × 10⁹/L
Haemoglobin	14.1 g/dL	13.0-17.0 g/dL
Haematocrit	42%	40-54%
Platelets	248 × 10⁹/L	150-400 × 10⁹/L
CRP (C-Reactive Protein)	38 mg/L	<5 mg/L
Serum Urea	4.8 mmol/L	2.5-6.7 mmol/L
Serum Creatinine	78 µmol/L	62-115 µmol/L
Serum Amylase	52 U/L	30-110 U/L
Serum Bilirubin	11 µmol/L	<21 µmol/L
ALT	22 U/L	7-40 U/L
Serum Electrolytes	Na 138, K 3.9	Within normal limits
Blood Glucose	5.4 mmol/L	3.9-5.6 mmol/L
Coagulation screen (PT/APTT)	Normal	-
Blood group & save	Group O+, antibody screen negative	-

Note: Amylase within normal limits -- pancreatitis effectively excluded. Leucocytosis with neutrophilia is consistent with acute bacterial inflammation.

Urine Analysis

Midstream urine (MSU) dipstick: Negative for nitrites, leucocytes, blood, protein.
No haematuria -- renal/ureteric colic less likely.
Urine microscopy and culture: Sent (pending).

Imaging

Erect Chest X-Ray (CXR):

No free air under the diaphragm (no evidence of visceral perforation at this time).
No consolidation, no pneumothorax.
Normal cardiac silhouette.

Abdominal Ultrasound (USS):

Performed by senior sonographer. The appendix was visualised in the right iliac fossa.
Findings: Non-compressible tubular structure in the RIF measuring 8 mm in outer diameter (>6 mm is abnormal). No appendicolith seen. Increased echogenicity of the surrounding periappendiceal fat, consistent with fat stranding. No free fluid in the pelvis. No free peritoneal gas. No other abnormality identified.
Conclusion: Sonographic findings are consistent with acute appendicitis.

CT Abdomen and Pelvis (with IV contrast) -- performed given diagnostic confidence needed for operative planning:

Dilated, thickened appendix measuring 9 mm.
Periappendiceal fat stranding.
No evidence of perforation, abscess, or free intraperitoneal gas.
No appendicolith on CT.
No other intra-abdominal pathology.
Conclusion: Acute uncomplicated appendicitis.

(CT was added here as supplementary confirmation; in straightforward cases with a high Alvarado score and positive USS, CT is not always required. It is particularly valuable when the USS is inconclusive or in atypical presentations.)

4. DIAGNOSIS

Primary Diagnosis: Acute uncomplicated appendicitis

Alvarado Score: 9/10 -- high probability.

Differential diagnoses considered and effectively excluded:

Mesenteric adenitis (no recent URTI, no bilateral tenderness)
Renal/ureteric colic (clean urine dipstick, character of pain)
Meckel's diverticulitis (same surgical management; excluded intraoperatively)
Right-sided ovarian pathology (not applicable -- male patient)
Acute pancreatitis (normal amylase)
Testicular torsion (both testes palpated normally)

5. MANAGEMENT IN HOSPITAL

5a. Immediate Resuscitation and Pre-operative Preparation

IV access: Large-bore (16G) IV cannula sited in the right antecubital fossa. Blood samples taken simultaneously.
IV fluid resuscitation: Normal saline (0.9% NaCl) 1000 mL over 1 hour, then maintenance IV fluids at 125 mL/hour. Patient was mildly dehydrated from reduced oral intake and vomiting.
Nil by mouth (NBM): Patient made NBM in preparation for theatre.
Analgesia: IV morphine 5 mg with IV ondansetron 4 mg anti-emetic given. (Adequate analgesia does not mask clinical signs and should not be withheld.)
Pre-operative IV antibiotics: As per local protocol -- IV Co-amoxiclav 1.2 g (or alternatively IV Cefuroxime 1.5 g + Metronidazole 500 mg) given at induction of anaesthesia. This covers Gram-negative enteric organisms and anaerobes.
DVT prophylaxis: TED stockings applied. Low molecular weight heparin (LMWH) -- Enoxaparin 40 mg SC -- given pre-operatively.
Urinary catheter: Inserted to monitor urine output during surgery and decompressed bladder pre-operatively.
Informed consent: Full explanation of the procedure, anaesthetic risk, and complications (wound infection, bleeding, injury to bowel/vessels, conversion to open, risk of negative laparoscopy). Written consent obtained.
Anaesthetic review: Pre-operative anaesthetic assessment done. ASA Grade I. No anticipated airway difficulty.

5b. Operative Management - Laparoscopic Appendectomy

The patient was taken to theatre approximately 8 hours after diagnosis. Laparoscopic appendectomy was performed under general anaesthesia in the standard fashion.

Operative Findings:

Three port technique: 10 mm umbilical port (camera), 5 mm left iliac fossa port, 5 mm suprapubic port.
On entry, the appendix was identified in a retrocaecal position. It appeared hyperaemic, oedematous, and covered in fibrinous exudate with early purulent exudate extending to the mesoappendix -- consistent with acute appendicitis with early serosal involvement.
No frank perforation. No free pus in the peritoneal cavity. No appendiceal mass or phlegmon.
The mesoappendix was divided and ligated using an Endo-loop/diathermy. The base of the appendix was doubly ligated with Endo-loops and divided. The appendix was retrieved in an Endo-bag to avoid wound contamination.
Peritoneal cavity irrigated with warm saline.
Haemostasis confirmed. Ports closed in layers.

Operative Time: 45 minutes. Blood Loss: Minimal (<20 mL). Specimen: Appendix sent for histopathological examination.

Acute appendicitis histology - pus-filled lumen (L) with inflammation extending to the serosa (S)

Histopathology (as above): pus-filled lumen (L) with acute inflammatory infiltrate extending through all layers to the inflamed serosa (S). (From Bailey & Love's Short Practice of Surgery, 28th ed.)

5c. Post-operative Management

Day 0 (Day of Surgery):

Transferred to recovery, then surgical ward. Monitored hourly for 4 hours: HR, BP, RR, O2 sats, urine output.
IV fluids continued.
Regular IV analgesia: Paracetamol 1 g QDS + Ibuprofen 400 mg TDS (if no contraindication).
Breakthrough analgesia: IV/IM morphine PRN.
NBM until fully awake and tolerating sips, then progressed to free fluids.
Urinary catheter removed once patient ambulant.

Day 1 Post-operative:

Patient afebrile (36.8°C).
Tolerating light diet.
IV antibiotics: Post-operative antibiotics not routinely continued for uncomplicated appendicitis (single pre-operative dose is sufficient per evidence-based guidelines for uncomplicated cases).
IV fluids discontinued once tolerating oral fluids.
Patient mobilised with physiotherapy.
Wound check: Three port sites clean, no bleeding, no haematoma.

Day 2 Post-operative:

Fully ambulant. Tolerating normal diet. Bowel sounds present. No fever.
Pain well controlled on oral paracetamol and ibuprofen.
Repeat WBC: 9.8 × 10⁹/L (trending down).
Bloods otherwise normal.

Discharge (Day 2 post-operative):

Patient discharged home on Day 2 in good condition.

Discharge Medications:

Paracetamol 1 g PO QDS PRN for 5 days.
Ibuprofen 400 mg PO TDS with food PRN for 5 days.

Discharge Advice:

No heavy lifting or strenuous activity for 2 weeks.
Keep wounds dry for 48 hours; dry dressings in place.
Return to ED if: increasing pain, fever >38°C, wound redness/discharge, or vomiting.
Follow-up appointment in surgical outpatient clinic at 2 weeks for wound review and histology result.

Histology Result (reported at 2-week follow-up):

Confirmed acute suppurative appendicitis with neutrophilic transmural inflammation. No evidence of malignancy, no Crohn's disease.

SUMMARY

This was a 22-year-old male who presented with the classic triad of periumbilical pain migrating to the RIF, anorexia, and a single episode of vomiting, with low-grade fever and leucocytosis (WBC 14.2, neutrophilia 83%, CRP 38). His Alvarado score was 9/10, USS confirmed an 8 mm non-compressible appendix with fat stranding, and CT confirmed uncomplicated appendicitis. He underwent an uncomplicated laparoscopic appendectomy and was discharged home on post-operative day 2.

Sources:

Bailey & Love's Short Practice of Surgery, 28th ed., Ch. 76 (History, Physical Signs, Differential Diagnosis of Appendicitis)
Sabiston Textbook of Surgery, Treatment of Appendicitis
Schwartz's Principles of Surgery, 11th ed., The Appendix
Tintinalli's Emergency Medicine - Clinical Features of Appendicitis
Robbins & Kumar Basic Pathology - Acute Appendicitis (Morphology and Clinical Features)
