Cleft Lip and Palate - Repair
1. Introduction
2. Incidence and Distribution
- Cleft lip alone: 15%
- Cleft lip + palate: 45%
- Isolated cleft palate: 40%
3. Aetiology
- Genetic: First-degree family history significantly raises recurrence risk. Mutations affecting IRF6, TP63, BMP4, and FGFR genes are implicated.
- Environmental/maternal factors:
- Maternal smoking
- Alcohol use
- Anticonvulsant drugs (phenytoin, valproate, carbamazepine)
- Folic acid deficiency
- Teratogen exposure in first trimester
4. Classification
- Isolated cleft palate
- Cleft lip with or without alveolus or palate involvement (unilateral or bilateral)
- Laterality (left/right/bilateral)
- Completeness (complete vs. incomplete)
- Involvement (lip only, lip + alveolus, lip + alveolus + palate)
5. Pathological Anatomy
Cleft Lip Anatomy
- The orbicularis oris muscle is discontinuous and inserts abnormally onto the lateral pyriform aperture and columella, rather than crossing the midline
- In unilateral cleft: nasiolabial and bilabial muscle chains are disrupted unilaterally, causing nasal flaring on the affected side
- In bilateral cleft: disruption is symmetric, with a protrusive premaxilla, flared nostrils, and a skin island (the prolabium) in front of the premaxilla that is devoid of muscle
Cleft Palate Anatomy
- The levator veli palatini muscles insert abnormally anteriorly into the hard palate rather than forming a posterior transverse sling
- Normal levator sling is absent, compromising velopharyngeal closure
- Hard palate: three mucosal zones - central palatal fibromucosa (thin, nasal floor), maxillary fibromucosa (thick, contains greater palatine neurovascular bundle), and gingival fibromucosa
- In complete cleft palate, the median palatal vault is absent and palatal fibromucosa is reduced
6. Multidisciplinary Team (MDT)
| Team Member | Role |
|---|---|
| Cleft coordinator/administrator | Organises patient pathway and surgical episodes |
| Clinical Nurse Specialist (CNS) | First contact; feeding, airway, family support |
| Paediatrician | Manages associated medical conditions (cardiac, respiratory) |
| Plastic/maxillofacial surgeon | Primary and secondary surgical repair |
| Speech and Language Therapist (SLT) | Monitors speech development, diagnoses VPI |
| ENT/Audiologist | Hearing screening, management of OME |
| Paediatric dentist | Dental disease prevention |
| Orthodontist | Dentofacial growth monitoring, pre-surgical orthopaedics |
| Psychologist | Psychosocial support for child and family |
| Geneticist | Counselling where syndromic association is suspected |
7. Presurgical Preparation
Feeding
- Specialised squeeze bottles (e.g., Haberman feeder)
- Specially shaped teats
- Nasogastric tube in severe cases
Presurgical Infant Orthopaedics / Nasoalveolar Moulding (NAM)
- An individually moulded oral plate with nasal stents is fitted shortly after birth
- Worn full time, regularly adjusted to reshape nasal cartilages and columella
- Aims to reduce severity of the cleft deformity and improve nasal symmetry before surgery
- Evidence remains mixed, but positive results have been shown for improving nasal symmetry in unilateral CLP patients
- Lip adhesion: taping/surgical approximation of lateral lip segments to the premaxilla - controversial and not strongly supported in literature
8. Staged Surgical Management
| Age | Procedure |
|---|---|
| 3-6 months | Cleft lip repair ± primary nasal repair ± hard palate (vomerine flap) |
| 9-12 months | Cleft palate repair (soft palate ± hard palate) ± ventilation tubes |
| 4-5 years | Secondary speech surgery if VPI persists (pharyngoplasty) |
| 7-9 years | Alveolar bone graft (ABG) |
| 15-18 years | Secondary rhinoplasty |
| 16+ years | Orthognathic surgery if required |
9. Cleft Lip Repair (Cheiloplasty)
- Restore muscular continuity of orbicularis oris
- Reconstruct a symmetrical Cupid's bow with minimal scarring
- Achieve symmetrical nasal sill and philtral columns
- Avoid straight-line scars across the lip
Techniques for Unilateral Cleft Lip Repair
| Technique | Description |
|---|---|
| Millard rotation-advancement (most widely used) | Rotation flap from the philtral column medially + advancement flap from the lateral lip. Scar placed along the philtral column. Flexible, can be modified intraoperatively. |
| Tennison-Randall (triangular flap) | Geometric triangular flap inserted into the medial lip element to gain height. More mathematically precise, less adaptable. |
| Fisher anatomic subunit repair | Uses anthropometric landmarks to recreate philtral subunit anatomy. Increasingly popular in UK. |
| Rose-Thompson straight-line repair | Simple straight-line closure; only suitable for incomplete minor clefts. |
Bilateral Cleft Lip Repair
- More challenging due to absent muscle in prolabium and protrusive premaxilla
- Muscle is brought across from both lateral lip elements and sutured in the midline
- Modified Millard technique is commonly used
- Premaxillary setback (surgical or orthopaedic) may be needed preoperatively to reduce tension
10. Anterior Palate (Hard Palate) Closure
- In complete CLP, the anterior palate (primary palate) is closed at the time of lip repair using a single-layer vomerine mucosal flap
- The vomer flap is raised and sutured to the nasal mucosa of the opposite cleft edge
- Avoidance of denuded bone surfaces is important as periosteal stripping impairs maxillary growth
11. Cleft Palate Repair (Palatoplasty)
- Avoid straight-line closure on the soft palate
- Avoid or minimise lateral relaxing incisions over the hard palate (impairs growth)
- Meticulous technique, often under optical magnification
Techniques
a) Intravelar Veloplasty (IVVP) - Sommerlad technique
- Most common approach in the UK
- Radical dissection of the velar (levator veli palatini) muscles from their abnormal anterior insertions
- Muscles are reorientated transversely and sutured together in the midline to recreate an anatomical levator sling
- Nasal and oral mucosae are dissected free from the muscles and closed separately over the newly formed sling
- Associated with good speech outcomes
b) Furlow Double-Opposing Z-Plasty
- Uses two Z-plasties (one on oral surface, one on nasal surface) oriented in opposite directions
- Results in lengthening of the soft palate and posterior repositioning of levator muscles
- Useful where palatal length is deficient
- Associated with good speech outcomes; some degree of asymmetry
- No difference in audiological outcomes compared to IVVP
c) Von Langenbeck Repair
- Bipedicled mucoperiosteal flaps raised along the hard palate
- Oral and nasal mucosae closed in layers
- Lateral relaxing incisions used
- Risk of maxillary growth restriction due to lateral denuded bone
d) Veau-Wardill-Kilner (VWK) / V-Y Pushback
- Mucoperiosteal flaps are retracted posteriorly to lengthen the palate
- More bone left exposed - greater risk of growth impairment
- Largely abandoned in favour of IVVP
12. Primary Nasal Repair (Rhinoplasty)
- The cleft nose deformity is characterised by: asymmetric nasal tip, deviated septum, asymmetric nasal bones, displaced lower lateral cartilage on the affected side
- Primary rhinoplasty at the time of lip repair: repositions alar cartilages and nasal tip
- Definitive secondary rhinoplasty is deferred to adolescence (15-18 years) after facial skeletal growth is complete
- Evidence supports that primary rhinoplasty achieves stable long-term results with limited growth disturbance
13. Alveolar Bone Grafting (ABG)
- Performed at 7-9 years of age (mixed dentition phase), before eruption of permanent canine teeth
- Cancellous bone is harvested from the iliac crest (occasionally cranium or rib) and packed into the alveolar cleft
- Aims to:
- Provide bony continuity to the alveolar arch
- Support eruption of the permanent canine
- Stabilise the premaxilla in bilateral cases
- Allow later orthodontic treatment
14. Secondary Surgery and Long-Term Management
Velopharyngeal Incompetence (VPI)
- VPI arises when the repaired soft palate fails to achieve adequate velopharyngeal closure
- Presents as hypernasal speech, nasal air escape, and compensatory articulation errors
- Investigated with lateral videofluoroscopy and nasendoscopy
- Managed with:
- Re-repair / secondary palatoplasty (when levator muscle insertion is anterior)
- Pharyngoplasty: creates a partial obstruction at the velopharyngeal port
- Posterior pharyngeal flap: midline flap from posterior pharyngeal wall sutured to soft palate
- Sphincter pharyngoplasty: medial transposition of lateral pharyngeal wall flaps
- Normal resonance achieved in up to 85% of cases
- Main risk: obstructive sleep apnoea (must be counselled preoperatively)
Hearing and OME
- Eustachian tube dysfunction is common with palatal clefts due to abnormal tensor veli palatini function
- High incidence of otitis media with effusion (OME) - "glue ear"
- Regular audiological screening essential
- Ventilation tubes (grommets) placed at the time of palate repair if OME is significant
Dental Anomalies
- Hypodontia or hyperdontia, most commonly involving the maxillary lateral incisor at the cleft site
- Delayed eruption, morphological abnormalities
- Regular paediatric dental review and orthodontic monitoring
Orthognathic Surgery
- Approximately 25% of CLP patients develop midface hypoplasia (Class III skeletal pattern) due to:
- Scar tethering from previous repairs
- Intrinsic growth restriction of the maxilla
- Le Fort I maxillary advancement ± mandibular osteotomy performed at 16+ years after skeletal maturity
15. Complications of Cleft Repair
| Complication | Management |
|---|---|
| Wound dehiscence | Re-repair when healed |
| Oronasal fistula | Secondary fistula repair |
| VPI / hypernasality | Speech therapy, pharyngoplasty |
| Midface hypoplasia | Orthognathic surgery |
| Nasal deformity | Secondary rhinoplasty |
| OME / hearing loss | Grommets, hearing aids |
| Dental anomalies | Orthodontics, prosthetics |
| Hypertrophic scarring | Scar management, revision |
16. Outcomes
- Experience of the cleft surgeon and MDT
- Timing of surgery
- Quality of muscle reconstruction
- Long-term orthodontic and speech follow-up
- Acceptable lip aesthetics
- Normal or near-normal speech
- Functional dentition
- Acceptable nasal appearance after rhinoplasty
