Internuclear Ophthalmoplegia (INO)
Definition
Internuclear ophthalmoplegia is a disorder of conjugate horizontal eye movement caused by a lesion in the medial longitudinal fasciculus (MLF) - the brainstem tract that coordinates communication between the abducens nucleus (CN VI, in the pons) and the contralateral oculomotor nucleus (CN III, in the midbrain).
- Bradley and Daroff's Neurology in Clinical Practice, p. 257
- Kanski's Clinical Ophthalmology, 10th ed., p. 836
Anatomy and Pathophysiology
The Normal Horizontal Gaze Circuit
For the eyes to look right, for example:
- The right PPRF (paramedian pontine reticular formation) fires the right abducens nucleus (CN VI)
- The right CN VI does two things simultaneously:
- Drives the right lateral rectus (right eye abducts)
- Sends an internuclear signal up the left MLF to the left CN III nucleus - which drives the left medial rectus (left eye adducts)
- Both eyes move right together - conjugate gaze
What Goes Wrong in INO
A lesion of the MLF on one side breaks this internuclear connection. The ipsilateral medial rectus no longer receives its signal during horizontal gaze away from the lesion side.
Result:
- The ipsilateral eye fails to adduct (or adducts slowly/incompletely) when attempting contralateral gaze
- The contralateral eye abducts normally but shows nystagmus (ataxic/dissociated nystagmus) - it "overshoots" because it's not getting the normal dampening signal
The side of the lesion is named for the side of the adduction deficit (not the nystagmus side).
- Bradley and Daroff's, p. 902
- Scott-Brown's Otorhinolaryngology, p. 3228
Classic Clinical Signs
| Sign | Detail |
|---|
| Adduction deficit | Ipsilateral eye fails/slows to adduct on contralateral gaze |
| Abducting nystagmus | Contralateral (abducting) eye shows horizontal nystagmus |
| Primary position | Eyes often straight (no deviation at rest) |
| Convergence | Intact if lesion is anterior/discrete; impaired if posterior or extensive |
| Vertical pursuit | May be abnormal (MLF also carries vertical VOR signals) |
| Skew deviation | May occur - vertical ocular misalignment from otolith pathway damage |
- Kanski's Clinical Ophthalmology, p. 836
- Bradley and Daroff's, p. 3025-3029
Clinical Photographs
Left INO - from Kanski's Clinical Ophthalmology:
Fig. 19.83: Left INO. (A) Straight eyes in primary position. (B) Left eye fails to adduct on right gaze. (C) Normal left abduction preserved.
Bilateral INO:
Fig. 19.84: Bilateral INO. (A) Left adduction limited on right gaze. (B) Right adduction limited on left gaze. (C) Convergence is preserved.
Unilateral vs. Bilateral INO
Unilateral INO
- Defective adduction of the eye on the side of the lesion
- Gaze toward the side of the lesion is normal
- Most common causes: stroke (older patients), multiple sclerosis (younger patients)
- Demyelinating and small vascular lesions are the most common causes when unaccompanied by other brainstem signs
Bilateral INO
-
Both eyes fail to adduct in opposite directions
-
Limitation of left adduction on right gaze AND limitation of right adduction on left gaze
-
Bilateral INO in a young adult is virtually diagnostic of MS (Adams & Victor's, p. 261)
-
Convergence may be intact or impaired
-
A rostral midbrain lesion can produce WEBINO (Wall-Eyed Bilateral INO) - bilateral exotropia with convergence deficit
-
Goldman-Cecil Medicine, p. 1405
-
Adams and Victor's Principles of Neurology, 12th ed.
Causes
| Category | Specific Causes |
|---|
| Demyelination | Multiple sclerosis (most common in young adults, especially bilateral) |
| Vascular | Brainstem stroke (most common in older adults), vertebral artery dissection, small vessel infarction |
| Structural | Tumour, brainstem compression (subdural haematoma, transtentorial herniation, cerebellar mass) |
| Inflammatory/Infectious | Vasculitis, infections |
| Traumatic | Head trauma |
| Iatrogenic | Post-surgical |
| Mimics | Myasthenia gravis (MG), Guillain-Barre syndrome, Miller Fisher syndrome |
One large series found approximately 1/3 stroke, 1/3 MS, 1/3 other causes (Keane, 2005) - cited in Bradley and Daroff's, p. 3033
Symptoms
Surprisingly, most patients with INO are asymptomatic. When symptoms occur:
-
Diplopia - horizontal (from medial rectus paresis) or vertical (from skew deviation)
-
Oscillopsia - one image appears to jiggle
-
Blurred vision
-
Bradley and Daroff's, p. 3027
Variants and Related Syndromes
WEBINO (Wall-Eyed Bilateral INO)
- Rostral midbrain lesion producing bilateral INO + convergence deficit
- Results in bilateral exotropia (wall-eyed) with abducting nystagmus bilaterally
One-and-a-Half Syndrome
- Combined lesion of the PPRF (or abducens nucleus) + MLF on the same side
- Results in: ipsilateral gaze palsy (the "one") + ipsilateral INO (the "half")
- Only preserved movement: abduction of the contralateral eye (with nystagmus)
- Kanski's, p. 836
Eight-and-a-Half Syndrome
- One-and-a-half syndrome + ipsilateral facial nerve (CN VII) palsy
- Due to dorsal tegmental caudal pontine lesion involving PPRF/abducens nucleus + MLF + CN VII fascicles
- Localization in Clinical Neurology, 8e
Differentiating INO from Mimics
| Condition | Convergence | Other features |
|---|
| True INO (MLF lesion) | Intact (if anterior) | Nystagmus in abducting eye; no ptosis |
| Partial CN III palsy | Impaired | May have ptosis, pupil changes |
| Myasthenia gravis | Variable, fatigable | Ptosis, positive Tensilon test, fatigability |
| Thyroid eye disease | Normal | Proptosis, lid retraction, restriction pattern |
| Strabismus | Normal | Long history, no nystagmus |
The key distinguishing feature: intact convergence in an isolated MLF lesion (the medial rectus works for convergence via a different pathway) but impaired adduction during horizontal gaze. - Bradley and Daroff's, p. 3033
Investigations
- MRI brain (with thin-cut pontine sequences) - modality of choice; may show demyelinating plaque or infarct in the MLF. T2-weighted imaging can reveal hyperintense lesion in the MLF
- If associated signs suggest MG, do acetylcholine receptor antibodies, Tensilon test
- Vascular workup (CTA/MRA, vessel imaging) if stroke is suspected
Treatment
Treatment is directed at the underlying cause:
- MS: disease-modifying therapy
- Stroke: antiplatelet/anticoagulation, thrombolysis if acute
- Strabismus surgery may be offered for persistent diplopia that doesn't resolve spontaneously
Most cases of INO improve partially or fully once the underlying cause is treated. Prism glasses can help with persistent diplopia in the interim.
- Kanski's Clinical Ophthalmology, p. 836
