ESBL Detection Methods — Detailed Lab Methodology
What Are ESBLs? (Brief Background)
ESBLs (Extended-Spectrum Beta-Lactamases) are plasmid-derived enzymes that:
- Confer resistance to penicillins, 1st–3rd generation cephalosporins, and aztreonam
- Are inhibited by β-lactamase inhibitors (clavulanate, sulbactam, tazobactam) — this is the key principle behind detection
- Remain susceptible to carbapenems and cephamycins (unless co-resistance exists)
- Main families in India: CTX-M, SHV, TEM — CTX-M-15 is dominant
— Henry's Clinical Diagnosis and Management by Laboratory Methods
DETECTION METHODS — Step by Step
METHOD 1: Double Disc Synergy Test (DDST)
Most commonly used in Indian studies
| Parameter | Detail |
|---|
| Principle | Synergy between a cephalosporin disc and amoxicillin-clavulanate disc |
| Discs used | Cefotaxime (30µg), Ceftazidime (30µg), Ceftriaxone (30µg), Cefepime (30µg) placed 15–20 mm from Augmentin (AMC 20/10µg) disc |
| Medium | Mueller-Hinton Agar |
| Reading | Positive: Enhancement/distortion ("keyhole zone") of inhibition zone towards AMC disc |
| Organisms | E. coli ATCC 25922 (negative control), K. pneumoniae ATCC 700603 (positive control) |
| Sensitivity | ~80–90% — can miss some CTX-M producers if distance not optimised |
METHOD 2: Combined Disc Test (CDT) / Phenotypic Confirmatory Test
CLSI-recommended standard method
| Parameter | Detail |
|---|
| Principle | Comparison of zone diameters: cephalosporin disc alone vs. cephalosporin + clavulanate disc |
| Discs | Cefotaxime (30µg) + Cefotaxime/Clavulanate (30/10µg); Ceftazidime (30µg) + Ceftazidime/Clavulanate (30/10µg) |
| Reading | Positive: ≥5 mm increase in zone diameter in the +clavulanate disc compared to alone |
| Standard | CLSI M100 (current guideline) |
| Notes | Two pairs of discs used because CTX-M favours cefotaxime; TEM favours ceftazidime |
METHOD 3: E-Test (Epsilometer Test) for ESBL
Gold standard phenotypic confirmation
| Parameter | Detail |
|---|
| Principle | Bi-phasic strip: one end has cefotaxime (CT), other end has cefotaxime + clavulanate (CTL); same for ceftazidime/TZ–TZL |
| Reading | Positive: MIC ratio CT/CTL ≥8 OR TZ/TZL ≥8; OR presence of "phantom zone" or deformed ellipse |
| Example | K. pneumoniae: TZ = >32, TZL = 0.75 → ratio = 43 → ESBL positive |
| Cost | More expensive; used mainly in reference/teaching labs |
E-test strips: Left plate = ESBL-producing K. pneumoniae (positive). Right plate = non-ESBL E. coli (negative). The deformed/phantom ellipse on the K. pneumoniae plate is a positive ESBL indicator.
— Henry's Clinical Diagnosis and Management by Laboratory Methods, p. 1346
METHOD 4: Automated Susceptibility Testing (Vitek-2 / MicroScan / BD Phoenix)
| Parameter | Detail |
|---|
| Principle | Incorporates ESBL screening cards with automated MIC reading |
| Screening | Higher MICs to 3rd-generation cephalosporins triggers ESBL flag |
| Confirmation | System internally compares ± clavulanate MICs |
| Advantage | Simultaneous screening + confirmation; standardised |
| Indian use | Used in NABL-accredited tertiary hospitals (AIIMS, PGI, JIPMER, etc.) |
METHOD 5: Molecular Methods — PCR
Used in research/surveillance studies (including Indian studies)
| Gene target | ESBL type | Notes |
|---|
| blaCTX-M | CTX-M group | Most important in India; CTX-M-15 dominant |
| blaSHV | SHV group | Common in Klebsiella |
| blaTEM | TEM group | Common in E. coli |
- Multiplex PCR can detect all three simultaneously
- PCR is the definitive confirmation method — used to characterise outbreak strains
- Does not replace phenotypic testing for routine clinical labs
METHOD 6: Whole Genome Sequencing (WGS)
Reference/outbreak investigation only
- 95–99.7% concordance with phenotypic AST for E. coli and K. pneumoniae
- Identifies resistance genes, plasmid types, virulence factors
- Can predict MICs using machine learning
- Not used for routine clinical lab due to cost and bioinformatics requirements
- Used in India for surveillance studies (e.g., ICMR AMR network)
— Henry's Clinical Diagnosis and Management by Laboratory Methods, p. 1350
CLSI Screening Criteria (Current Standard)
Isolates should be screened for ESBL if MIC is:
| Antibiotic | Screening MIC threshold |
|---|
| Cefpodoxime | ≥2 µg/mL |
| Cefotaxime | ≥2 µg/mL |
| Ceftazidime | ≥2 µg/mL |
| Ceftriaxone | ≥2 µg/mL |
| Aztreonam | ≥2 µg/mL |
Note: With current (revised lower) CLSI breakpoints, formal ESBL confirmation is no longer mandatory — MIC results alone are considered sufficient for treatment decisions. However, many Indian labs still perform confirmatory testing as standard practice and for infection control.
Practical Algorithm Used in Indian Tertiary Hospitals
Urine Culture → E. coli / Klebsiella growth
↓
Kirby-Bauer Disc Diffusion (Cefotaxime, Ceftazidime)
↓
Reduced zone or resistant? → Screen for ESBL
↓
Phenotypic Confirmatory Test (CDT / DDST)
↓
ESBL Positive → Report, Notify Clinician
↓
Treatment: Carbapenem (severe) / Nitrofurantoin / Fosfomycin (uncomplicated UTI)
↓
Research labs → PCR (blaCTX-M, blaSHV, blaTEM) for typing
