Medical Instruments & Drugs - Images and Clinical Uses

Here is a complete illustrated guide to each instrument and drug you listed, organized by specialty area.

ENT / General Examination Instruments

1. Probe (General Examination Probe)

A slender, blunt-tipped stainless steel instrument used to:

Explore wounds, fistulas, and sinuses
Probe lacrimal ducts (lacrimal probe)
Assess depth or direction of a tract or cavity
Aid in identifying structures during surgery

2. Jacobson (Micro) Probe

A very fine, delicate neurosurgical and microsurgical probe with a small hook or angled tip. Uses:

Dissecting fine tissues in microsurgery (ear, brain, spine)
Middle ear surgery (tympanoplasty, ossiculoplasty) - used to probe the ossicular chain (malleus, incus, stapes)
Identifying and separating nerves or vessels in the surgical field
Assessing mobility of the stapes footplate in otosclerosis surgery

3. Jobson-Horne Probe (Ear Probe / Ring Curette)

A thin wire probe with a small ring curette at one end and a wax hook at the other. Uses:

Removing ear wax (cerumen) from the external auditory canal
Probing aural polyps and masses
Examining and clearing debris from the ear canal
Standard ENT diagnostic instrument

4. Scoop (Ear Scoop / Wax Curette)

A small spoon-shaped or angled scoop instrument. Uses:

Scooping out impacted cerumen (ear wax) from the ear canal
Removing foreign bodies from the ear
Cleaning the external auditory meatus before otoscopic examination
Also used in nasal procedures to remove soft debris

5. Otoscope

(Part of the diagnostic ENT set below)

Diagnostic ENT Set with Otoscope & Ophthalmoscope

A handheld instrument with a light source, magnifying lens, and disposable aural speculum. Uses:

Examination of the external auditory canal and tympanic membrane (eardrum)
Diagnosing otitis externa, otitis media, perforation, cholesteatoma
Detecting foreign bodies in the ear
Can also be used for anterior rhinoscopy (nose examination) in children using a large speculum
Screens for hearing-related pathology in primary care and emergency settings

6. Torch (Penlight / Clinical Torch)

A focused bright light source. Uses:

General inspection of the oral cavity, oropharynx, and throat
Pupillary light reflex testing (direct and consensual)
Examination of the ear with a speculum when a formal otoscope is unavailable
Skin and wound illumination
Transillumination of sinuses (frontal/maxillary)
Checking for a swinging flashlight test (RAPD - relative afferent pupillary defect)

7. Nasal Speculum (Thudichum Speculum)

A spring-loaded, bivalve stainless steel instrument that spreads the nostrils. Uses:

Anterior rhinoscopy - widening the nostril to inspect the nasal cavity using a headlight
Visualising the nasal septum, inferior and middle turbinates, nasal polyps, foreign bodies
Allows single-handed operation (Thudichum design) while the other hand holds a light
Used in ENT clinics, general practice, and emergency settings

From Cummings Otolaryngology: "A nasal speculum or an otoscope fitted with the largest speculum is used to inspect the inner aspect of the nasal cavities."

8. Laryngoscope Mirror (Laryngeal Mirror)

(Shown in the ENT set image above - the round mirror on a handle)

A small circular mirror mounted on a long, angled handle. Uses:

Indirect laryngoscopy - visualising the larynx, vocal cords, epiglottis, arytenoids, and subglottis
Examining the posterior pharynx, tonsils, base of tongue, and nasopharynx (with posterior rhinoscopy mirror)
Pre-warmed before use (40°C warm water or spirit lamp) to prevent fogging by breath
Standard ENT tool for diagnosing laryngitis, vocal cord palsy, laryngeal tumors, and foreign bodies

Dental Instruments

9. Dental Mirror (Mouth Mirror)

A small circular mirror on a handle, angled for intraoral use. Uses:

Indirect vision - viewing tooth surfaces not visible directly (posterior teeth, lingual/palatal surfaces)
Retraction of the cheek, tongue, or lips to improve access and visibility
Transillumination - reflecting light onto a tooth surface to detect caries or cracks
Inspecting restorations, gingiva, and oral mucosa
Checking for dental caries, plaque, calculus, and periodontal disease

10. Dental Probe (Explorer / Periodontal Probe)

Uses:

Caries detection - the sharp tip "catches" or sticks in softened enamel/dentine
Periodontal probing - measuring pocket depth (sulcus depth) around each tooth to assess periodontal disease
Detecting overhanging restorations, open margins, or calculus
Examining root surfaces after scaling
Periodontal probes are graduated (usually in mm markings at 3-3-2 or 3-6-8-11 mm intervals)

Ophthalmic Instruments

11. Retinoscope

(Part of the ophthalmic instrument set)

A handheld instrument that projects a beam of light into the eye and allows the clinician to observe the reflex from the retina. Uses:

Objective refraction - determining the refractive error (myopia, hyperopia, astigmatism) without requiring patient cooperation
Essential for refraction in children, infants, and non-verbal patients
The clinician neutralises the "with" or "against" movement of the retinal reflex using trial lenses
Two types: streak retinoscope (most common) and spot retinoscope

From Ganong's Physiology: "Refraction - Phoropter; retinoscope - Lens power needed for vision correction."

12. Ophthalmoscope (Direct Ophthalmoscope)

(Labelled in the diagnostic ENT set above)

A handheld device with a light source and multiple viewing lenses on a rotating disc. Uses:

Fundoscopy (fundus examination) - examining the optic disc, retina, macula, and retinal vessels
Detecting papilloedema (raised intracranial pressure), glaucomatous cupping, diabetic retinopathy, hypertensive retinopathy, retinal detachment
Routine screening in diabetes patients every 6-12 months
Emergency assessment of headache (looking for papilloedema)
Direct ophthalmoscopy gives 15x magnification, upright image

From Wills Eye Manual: "Whether the retina can be seen with a direct ophthalmoscope or retinoscope when looking through an undilated pupil - a blunted retinoscopic reflex suggests the cataract is significant."

13. Occluder

A flat opaque (black) paddle with a handle. Uses:

Occlusion of one eye during visual acuity testing to test each eye separately
Used in amblyopia testing and strabismus assessment
Pinhole occluder (one side has small pinholes of ~1 mm) is used together (see below)
Part of every ophthalmic and optometry examination kit

14. Pinhole

A dark disc with one or more ~1 mm holes. Uses:

Distinguishing refractive error from organic visual loss: if vision improves with pinhole, the problem is refractive (correctable with glasses); if vision does not improve, there is likely an organic (pathological) cause
Eliminates peripheral aberrations, allowing only central paraxial rays to enter
Quick test in emergency and general practice when glasses are unavailable
A card pierced with an 18-gauge needle can be used as an improvised pinhole

From Kanski's Clinical Ophthalmology: "A pinhole (PH) aperture compensates for the effect of refractive error, and consists of an opaque occluder perforated by one or more holes of about 1 mm diameter."

15. Trial Frame

A spectacle-like frame with adjustable cells that hold trial lenses. Uses:

Subjective refraction - inserting spherical and cylindrical trial lenses from the trial case to determine the best corrective prescription
Assessing the patient's vision with different lens combinations
Allows adjustment of pupillary distance (PD) and vertex distance
Used together with the Snellen chart and the retinoscope result as the starting point
Can hold occluder discs, pinhole discs, prisms, and coloured filters

Ophthalmic Drugs

16. Pilocarpine (Eye Drops)

A parasympathomimetic (muscarinic M3 agonist) drug. Ophthalmic uses:

Treatment of acute angle-closure glaucoma - causes miosis (pupil constriction), pulling the iris away from the trabecular meshwork and opening the drainage angle
Chronic open-angle glaucoma - reduces intraocular pressure by increasing aqueous outflow through the trabecular meshwork
Countering mydriasis after dilating drops or in cases of pharmacological pupil dilation
Accommodative esotropia (rarely used in children)
Used as 1%, 2%, or 4% eye drops

From Rosen's Emergency Medicine: "Parasympathomimetic miosis may be induced by exposures to organophosphate esters, pilocarpine drops..."

Property	Detail
Drug class	Muscarinic agonist (M3)
Effect on pupil	Miosis (constriction)
Effect on ciliary muscle	Spasm of accommodation
Main use	Angle-closure glaucoma, open-angle glaucoma
Concentration	1-4% drops

17. Tropicamide (Eye Drops)

A short-acting antimuscarinic (anticholinergic) mydriatic/cycloplegic agent. Ophthalmic uses:

Pupil dilation (mydriasis) for fundoscopic examination - relaxes the sphincter pupillae
Cycloplegia (paralysis of accommodation) - relaxes the ciliary muscle to allow more accurate refraction, especially in children (though atropine gives deeper cycloplegia)
Used before procedures: indirect ophthalmoscopy, slit lamp examination, cataract surgery prep
Short duration (~4-6 hours) makes it ideal for diagnostic dilation

From Wills Eye Manual: "One week after the laser PI, gonioscopy should be repeated prior to dilating the eye with a weak mydriatic (e.g., tropicamide 0.5%)."

From Goodman & Gilman's Pharmacology: tropicamide listed as M3/M4 muscarinic antagonist.

Property	Detail
Drug class	Muscarinic antagonist (M3/M4)
Effect on pupil	Mydriasis (dilation)
Effect on accommodation	Cycloplegia (paralysis)
Duration	~4-6 hours
Main use	Diagnostic fundoscopy, refraction, pre-op
Contraindication	Angle-closure glaucoma (may precipitate attack)

Quick Reference Summary Table

Instrument / Drug	Specialty	Primary Use
Probe	General/Surgical	Explore tracts, wounds, fistulas
Jacobson Probe	Microsurgery/ENT	Middle ear surgery, fine tissue dissection
Jobson-Horne Probe	ENT	Ear wax removal, ear canal examination
Scoop	ENT	Cerumen removal, ear foreign body
Otoscope	ENT	Ear canal & eardrum examination
Torch	General	Pupil reflex, oral/throat examination, transillumination
Nasal Speculum	ENT	Anterior rhinoscopy
Dental Mirror	Dentistry	Indirect vision, retraction, transillumination
Laryngoscope Mirror	ENT	Indirect laryngoscopy, vocal cord assessment
Dental Probe	Dentistry	Caries detection, periodontal pocket measurement
Retinoscope	Ophthalmology	Objective refraction (esp. children)
Ophthalmoscope	Ophthalmology	Fundus examination (retina, optic disc)
Occluder	Ophthalmology	Monocular visual acuity testing, cover test
Pinhole	Ophthalmology	Distinguish refractive vs. organic visual loss
Trial Frame	Ophthalmology	Subjective refraction with trial lenses
Pilocarpine	Ophthalmology	Glaucoma (miosis, reduces IOP)
Tropicamide	Ophthalmology	Mydriasis for fundoscopy, cycloplegia for refraction
