Chest X-Ray: From Basic Interpretation to Clinical Findings

Source: Grainger & Allison's Diagnostic Radiology; Pfenninger & Fowler's Procedures for Primary Care; Tintinalli's Emergency Medicine; Radiology Masterclass; LearningRadiology.com

PART 1: BASICS - HOW TO READ A CXR SYSTEMATICALLY

Technical Assessment First (ALWAYS)

Before looking at pathology, verify:

Parameter	Normal	Abnormal Clue
Patient identity & date	Labeled clearly	Missing = invalid film
Projection	PA (posteroanterior preferred)	AP films magnify heart
Rotation	Spinous process midway between clavicular heads	Rotation mimics mediastinal shift
Inspiration	5-6 anterior ribs visible	<5 = poor inspiration, mimics cardiomegaly/basal disease
Exposure	Vertebral bodies visible through heart, but ribs clear	Under = too white; Over = too dark

Systematic Approach: Inside-Out (ABCDE)

A - Airway (trachea midline, carina at T4-6, angle <70°) B - Bones & soft tissues (ribs, clavicles, scapulae, soft tissue) C - Cardiac silhouette (size, shape, borders) D - Diaphragm (levels, costophrenic angles, subdiaphragmatic) E - Everything else: lungs, hila, mediastinum, pleura

PART 2: KEY ANATOMICAL LANDMARKS ON A NORMAL CXR

Cardiac Borders (Silhouette Principle)

Structures touching each other produce a shared border. Loss of that border = pathology in the adjacent structure.

Border	Structure Forming It
Right upper heart border	SVC / ascending aorta
Right lower heart border	Right atrium
Left upper border	Aortic knuckle
Left mid border	Pulmonary trunk / left atrial appendage
Left lower border	Left ventricle

Cardiothoracic Ratio (CTR)

Normal CTR < 0.5 on PA film (heart width < half thoracic width)
CTR > 0.5 = cardiomegaly
AP films falsely increase CTR (portable films are AP - note this caveat)

Diaphragm

Right hemidiaphragm at level of 5th-6th anterior rib interspace
Right is higher than left in >90% of people (by ~15 mm, up to 30 mm)
Left has gas bubble underneath (stomach)

PART 3: THE FIVE CARDINAL OPACITIES (DENSITIES)

From whitest to blackest on CXR:

Metal (clips, pacemakers) - densest white
Bone (ribs, vertebrae)
Fluid/soft tissue (heart, consolidation, effusion)
Fat (slightly darker than soft tissue)
Air (lung, trachea) - blackest

Key principle: Two structures of the SAME density touching each other = their border disappears (Silhouette Sign).

PART 4: MAJOR PATHOLOGICAL FINDINGS

1. CONSOLIDATION (Air-Space Opacification)

Definition: Alveolar air replaced by fluid/pus/blood/cells, making the lung appear white/opaque.

X-ray features:

Homogeneous or patchy opacity
Air bronchogram - the hallmark: air-filled bronchi visible as dark branching lines against the white consolidated lung (only seen when the bronchi remain patent but surrounding alveoli are filled)
Ill-defined borders (unless bounded by a fissure)
No volume loss
Lobar or segmental distribution

Air Bronchogram - Classic Example:

Air bronchogram in consolidation/pneumonia - patent airways visible as dark branching lines against white opaque lung

Classic air bronchogram (highlighted in blue): black branching airways visible within the opacified consolidated lung - a hallmark of alveolar filling (Source: RadiologyMasterclass.co.uk)

Causes of consolidation and differentiating features:

Cause	Distinctive CXR Feature
Pneumonia (lobar)	Lobar/segmental distribution; air bronchogram; may cross segments; fever
Pulmonary edema	Bilateral perihilar "bat-wing" pattern; Kerley B lines; upper lobe venous diversion; cardiomegaly
Pulmonary infarction (PE)	Peripheral, wedge-shaped opacity (Hampton's hump); unilateral; near costophrenic angle
Pulmonary hemorrhage	Bilateral, diffuse; clears rapidly (24-48h); no fever
Alveolar cell carcinoma	Persistent consolidation not responding to antibiotics
Aspiration	Dependent zones (posterior lower lobes, right > left)

2. PLEURAL EFFUSION

Definition: Fluid accumulation in the pleural space.

X-ray features (erect PA view):

Small effusion (<200 mL): Blunting of lateral costophrenic angle (>200-500 mL needed to blunt the posterior CP angle on PA)
Moderate effusion: Homogeneous lower zone opacity with meniscus sign - concave upper border, higher laterally than medially
Large/massive effusion: Dense hemithoracic opacification, mediastinal shift to opposite side

Classic Pleural Effusion - Meniscus Sign:

Moderate left pleural effusion with meniscus sign - concave upper border higher laterally

(A) PA CXR showing left pleural effusion with meniscus sign; (C) CT coronal confirming left-sided fluid. - Grainger & Allison's Diagnostic Radiology

Massive Pleural Effusion With Mediastinal Shift:

Massive right pleural effusion with mediastinal shift to the left side

Massive pleural effusion causing mediastinal shift (A). CT coronal reconstruction confirms the massive effusion with compressed/atelectatic lung - Grainger & Allison

Important differentiating clues:

Finding	Effusion	Collapse	Consolidation
Mediastinal shift	Away from opacity	Towards opacity	None
Costophrenic angle	Blunted (meniscus)	May be blunted	Normal
Diaphragm	Elevated on side	Elevated	Normal
Air bronchogram	Absent	Absent (usually)	Present
Volume	Increased	Decreased	Normal/slight decrease

Absence of mediastinal shift with massive effusion = suspect ipsilateral lobar collapse OR malignant pleural disease (e.g., mesothelioma, which tethers the mediastinum).

Empyema:

Bilateral fluid collections: right = empyema (thick enhancing pleura on CT, "split pleura sign"); left = simple effusion. Note middle lobe pneumonia (C) - Grainger & Allison

Supine effusion (ICU/portable films):

No meniscus; fluid layers posteriorly
"Veil-like" hazy opacity over the entire hemithorax
Preserved vascular markings within the opacity
No air bronchograms

3. PNEUMOTHORAX

Definition: Air in the pleural space.

X-ray features (erect):

Visceral pleural line - thin white line separated from chest wall
Absent lung markings peripheral to that line
Lung collapse varies from small apical to complete

Classic Left-Sided Pneumothorax:

Left pneumothorax with visible visceral pleural line and absent lung markings, tracheal deviation

White arrows = visceral pleural line of pneumothorax; yellow arrow = deep sulcus sign at costophrenic angle; black arrow = tracheal deviation toward opposite side in tension pneumothorax. - LearningRadiology.com

Supine Pneumothorax - Deep Sulcus Sign:

Deep sulcus sign in supine pneumothorax - abnormally deep and sharp left costophrenic angle

In supine patients (ICU), air collects anteriorly/basally; the "deep sulcus sign" (circled) = abnormally deep, lucent, sharp costophrenic sulcus. Classic ICU finding. - TheCommonVein.com

Supine Pneumothorax (Bilateral Pneumonia Case):

Supine pneumothorax showing deep sulcus sign and increased lucency at left base

Portable CXR: Left-sided pneumothorax in supine patient with bilateral pneumonia. Increased lucency at left base and deep sulcus sign. - Grainger & Allison

Tension Pneumothorax (EMERGENCY):

All above features PLUS:
Mediastinal/tracheal deviation away from the side of pneumothorax
Ipsilateral diaphragm depression / inversion
Cardiovascular compromise - do NOT wait for X-ray to treat clinically!

Pneumothorax vs. Bulla/Skin fold - differentiating:

Feature	Pneumothorax	Bulla	Skin Fold
Pleural line	Thin, convex towards chest wall	Concave	Wider margin, wrong orientation
Vascular markings	Absent beyond line	May be present	Present
Accentuated on expiration	Yes	No	No

4. LOBAR COLLAPSE (ATELECTASIS)

Definition: Loss of air in a lobe or lung with volume reduction.

General CXR features of collapse:

Increased opacity (white) of the affected area
Volume loss: shift of fissures, trachea, hilum, mediastinum toward the collapse
Elevated hemidiaphragm on affected side
Crowding of ribs
Compensatory hyperinflation of remaining lung

Lobe-by-lobe findings:

Lobe	Key Sign on PA CXR	Other Features
Right upper lobe	Upward displacement of minor fissure; opacity in RUL	Tracheal deviation right; elevated right hilum
Right middle lobe	Loss of right heart border (silhouette sign); triangular density	Seen best on lateral view (narrow triangle)
Right lower lobe	Loss of right hemidiaphragm silhouette; opacity behind heart	Medial basal displacement; hilum depressed
Left upper lobe	"Veil-like" hazy opacity over entire left hemithorax	Loss of left heart border; "Luftsichel" sign (aortic knuckle visible)
Left lower lobe	Triangular opacity behind heart; loss of left diaphragm silhouette	Most common collapse in clinical practice

Silhouette Sign (essential concept):

"When an intrathoracic lesion is in anatomical contact with a border of the heart, aorta, or diaphragm, the normal radiographic silhouette of these structures is obliterated."

RML consolidation/collapse = loss of right heart border
Lingula disease = loss of left heart border
Right lower lobe = loss of right diaphragm silhouette
Left lower lobe = loss of left diaphragm silhouette

5. CARDIOMEGALY & HEART FAILURE

Cardiomegaly: CTR > 0.5 on PA film

Causes: Dilated cardiomyopathy, valvular disease, pericardial effusion, hypertensive heart disease, congenital.

Radiological stages of heart failure (ABCDE mnemonic):

Stage	Finding	Mechanism
A	Alveolar edema	Bat-wing/butterfly perihilar consolidations
B	Kerley B lines	1-2 cm horizontal lines at lung bases (interlobular septal thickening)
C	Cardiomegaly	CTR >0.5
D	Diversion of blood flow	Upper lobe vascular prominence/cephalization (vessels in upper zones ≥ same diameter as lower zone vessels)
E	Effusions	Bilateral (usually right > left) pleural effusions

Interstitial edema (earlier stage):

Kerley B lines (most specific)
Kerley A lines: 5-10 cm lines from hila toward periphery
Peribronchial cuffing: thickened bronchial walls seen end-on as "doughnuts"
Perihilar haziness

Alveolar edema (advanced):

Bilateral perihilar "bat-wing" consolidation with air bronchograms
Fluffy, cloud-like bilateral opacities
Rapid change between serial films (unlike pneumonia)

Differentiating cardiogenic vs. non-cardiogenic pulmonary edema (ARDS):

Feature	Cardiogenic	ARDS
Cardiomegaly	Yes	No
Cephalization	Yes	No
Pleural effusions	Common, bilateral	Uncommon
Kerley B lines	Yes	No
Distribution	Perihilar, central	Peripheral/diffuse
Air bronchograms	In alveolar edema	Diffuse, prominent

6. MEDIASTINAL ABNORMALITIES

Widened mediastinum (>8 cm at aortic arch level):

Trauma: aortic dissection/rupture - superior mediastinal widening, loss of aortic knuckle, tracheal deviation right, apical cap (blood)
Lymphadenopathy: bilateral hilar/paratracheal (sarcoidosis, lymphoma, TB)
Masses by location:

Compartment	Common Masses
Anterior (4 T's)	Thymoma, Teratoma, Terrible lymphoma, Thyroid
Middle	Lymphadenopathy, pericardial/bronchogenic cysts
Posterior	Neurogenic tumors, oesophageal pathology, vertebral disease

Hilar enlargement:

Bilateral symmetric = sarcoidosis (classic), lymphoma
Bilateral asymmetric = lymphoma, metastases, TB
Unilateral = lung cancer (hilar mass), pulmonary embolism (increased hilar opacity then pruning)

7. DIAPHRAGM ABNORMALITIES

Elevated hemidiaphragm (unilateral):

Phrenic nerve palsy
Subphrenic abscess
Hepatomegaly (right)
Lobar collapse (ipsilateral)
Splinting from pleurisy/pneumonia

Bilateral elevated diaphragm:

Poor inspiration (most common, technical)
Obesity / pregnancy
Ascites, abdominal distension
Diffuse pulmonary fibrosis
Bilateral basal PE
Lymphangitis carcinomatosa

Flattened diaphragm:

Emphysema (chronic hyperinflation)
Severe acute asthma

Inverted diaphragm:

Tension pneumothorax
Large bullae
Massive pleural effusion

8. INTERSTITIAL LUNG DISEASE (ILD) PATTERNS

Reticular pattern (net-like):

IPF: bibasal, peripheral honeycombing
Lymphangitis carcinomatosa: Kerley B lines, hilar adenopathy

Nodular pattern:

Military TB/miliary metastases: 1-3 mm diffuse tiny nodules
Sarcoidosis: upper/mid zone nodules + bilateral hilar adenopathy

Ground-glass opacity:

Pneumocystis jirovecii pneumonia (PJP): bilateral perihilar ground-glass
Early COVID-19: bilateral peripheral ground-glass
Alveolar proteinosis: "crazy paving" on CT

Honeycombing (cystic changes with fibrosis):

End-stage IPF; peripheral, bibasal

PART 5: DIFFERENTIATING THE "OPAQUE HEMITHORAX"

When one entire hemithorax is white, use these three clues to differentiate:

Condition	Mediastinal Shift	Air Bronchograms	Volume
Massive effusion	Away (opposite side)	Absent	Increased
Complete collapse	Toward (same side)	Absent	Decreased
Consolidation (entire lung)	None	Present	Normal
Pneumonectomy	Toward (same side)	None	Decreased

PART 6: QUICK CLINICAL CORRELATION TABLE

Condition	Key CXR Finding	Clinical Scenario
Lobar pneumonia	Lobar consolidation + air bronchogram + preserved volume	Fever, productive cough, pleuritic pain
Pulmonary edema	Bat-wing + Kerley B + cardiomegaly + cephalization	Acute dyspnea, orthopnea, S3 gallop
Pleural effusion	Blunted CP angle + meniscus	Dyspnea, dull percussion
Tension pneumothorax	Tracheal deviation + absent markings + mediastinal shift	Acute severe dyspnea + hypotension
Lobar collapse	Volume loss + opacity + shift toward + loss of border	Post-op, obstructing lesion, mucus plug
Aortic dissection	Widened mediastinum + loss of aortic knuckle	Tearing chest/back pain, hypertension
TB (primary)	Upper lobe consolidation + ipsilateral hilar adenopathy + pleural effusion	Night sweats, weight loss, hemoptysis
Sarcoidosis	Bilateral hilar lymphadenopathy ("potato nodes")	Incidental or with erythema nodosum
Malignancy	Perihilar mass + post-obstructive collapse	Smoker, hemoptysis, weight loss
ARDS	Diffuse bilateral consolidation, no cardiomegaly	ICU, sepsis, trauma, pancreatitis

PART 7: IMPORTANT RADIOLOGICAL SIGNS TO MEMORIZE

Sign	Meaning	Condition
Air bronchogram	Patent bronchi in opacified lung	Consolidation (pneumonia, edema)
Silhouette sign	Loss of border between adjacent same-density structures	Localizes disease to lobe/segment
Meniscus sign	Concave upper border of fluid, higher laterally	Free pleural effusion
Deep sulcus sign	Abnormally deep, sharp costophrenic angle	Pneumothorax on supine film
Kerley B lines	Short horizontal basal lines	Interstitial edema (heart failure)
Hampton's hump	Peripheral wedge-shaped opacity	Pulmonary infarct from PE
Westermark sign	Focal oligemia distal to PE	Pulmonary embolism
Luftsichel sign	Crescent of air around aortic knuckle	Left upper lobe collapse
Golden S sign	S-shaped fissure in RUL collapse	Central obstructing mass
Spine sign	Lower vertebrae appear denser on lateral	Lower lobe consolidation/mass
CT angiogram sign	Pulmonary vessels visible through dense consolidation	Bronchioloalveolar carcinoma

Summary: The 3-Step Approach at the Bedside

Is it opaque or lucent?

Opaque = consolidation, collapse, effusion, mass
Lucent = pneumothorax, emphysema, cyst/bulla

What is the volume?

Increased = effusion, mass
Decreased = collapse, fibrosis
Normal = consolidation, infarction

Where is the mediastinum?

Away from opacity = effusion
Toward opacity = collapse
Central = consolidation

This three-step framework lets you rapidly classify almost any CXR finding before thinking about specific diagnoses.

Primary references: Grainger & Allison's Diagnostic Radiology (9780323760751); Pfenninger & Fowler's Procedures for Primary Care (9780323052672); Tintinalli's Emergency Medicine (9781260019933); RadiologyMasterclass.co.uk; LearningRadiology.com

This is a shared conversation. Sign in to Orris to start your own chat.
